Axicon PV-1000便攜式一維條碼檢測儀
產品概述：
The PV-1000 unit can be used with any of the following linear barcode verifiers – the 6015, 6515 and 7015 - and it allows you to carry out verification without any connection to a laptop or PC. You can see the overall grade for each symbol, as well as the values for individual parameters while you are using it. The PV-1000 will also keep all your results as text or Axicon’s .scn files which you can transfer to your PC using a USB memory stick. This means the results can be recorded as part of any quality control system.
We can also supply a portable printer if you need to be able to print these reports immediately off-site. (If you already have a printer with a serial (RS232) connection, then this would work perfectly too.) Both the PV-1000 and the printer are battery powered and they will work for approximately 8 hours before needing to be recharged, or have the four AA batteries changed.
We also have a protective rubber cover for the PV-1000 which will give it greater protection, if you need this.
Please note that the PV-1000 is not compatible with any of the S-range or two-dimensional barcode verifiers.
Software specifications |
Symbologies verified |
EAN-8, EAN-13 and UPC-A (with or without add-ons), UPC-E, GS1 DataBar (all symbols), ITF-14, GS1-128, Code 39, Code 93, Code 128, Codabar, ITF, MSI Plessey, (all symbols no wider than 66mm) |
Analysis |
All ISO/IEC parameters, ANSI option, decodability per symbol character, nominal x-dimension, average bar gain, check digit validation, print contrast measurement (PCS), wide-to-narrow ratio, symbol structure, quiet zones. |
Calibration logging |
Record of date and time for ISO 9001 records |
Print Facilities |
Printing to optional serial printer from printer cable. Print records can be stored within the memory of the PV-1000 and then subsequently transferred to a PC via a USB memory stick for printing. |
Display window |
Two line LCD display |
Hardware specifications |
Dimensions |
180 x 95 x 40mm (7.2” x 3.8” x 1.6”) |
Weight |
400 gms (14oz) incl batteries |
Construction |
ABS plastic |
Interface and power
consumption |
USB. 4 AA size batteries – either alkaline or rechargeable NiMH. |
Hardware |
Can be used in conjunction with the following barcode verifiers: Axicon 6015, 6515 & 7015. |
General information |
Regulatory approvals |
CE marking (compliant with RoHS and EMC directives)
Compliant with ISO/IEC 15416 and ISO/IEC 15426-1
Can meet the requirements of 21 CFR part 11. |
Operating range |
Operating temperature: 0° to 50°C Storage temperature: -20° to 70°C Relative humidity: 5% to 95% @ 40°C non-condensing |
Warranty |
One year parts and labour – return to bench. |
