Axicon 12000, 12500, 12600, 12700,1200UV,1200omni二維條碼檢測儀
產品概述：
The Axicon 12000 series of two-dimensional barcode verifiers is intended for the verifying of Data Matrix, QR Code, GS1 DataMatrix, GS1 QR Code, GS1 DataBar, PDF and micro-PDF codes. Some models can also verify EAN/UPC, GS1-128 and ITF-14 codes, depending on their size. They are suitable for verifying symbols appearing on product packaging, promotional advertising, and literature, and the 12800 is specially designed for verifying direct-part-marked symbols used on surgical and medical devices, and component parts.
Features & Benefits
Fully compliant with ISO/IEC 15426-1 and 15426-2, the verifier conformance standards, and ISO/IEC 15415 and 15416, the barcode print quality specifications. They also provide the data files needed to meet the requirements of the USA CFR 21 part II regulations.
Hardware
CCD sensor-based 2D barcode verifier. Aperture selectable to suit application standard. Wavelength of light 660 nm.
12000 Series Specifications
Model
Number |
Field of view |
Light wavelength |
Aperture reference |
Symbols that can be verified |
12000 |
25mm x 18mm |
660nm |
03 - 20 |
GS1 DataMatrix |
12500 |
37mm x 25mm |
660nm |
03 - 20 |
GS1 DataMatrix, GS1 QR Code, QR Code, GS1 DataBar, EAN/UPC |
12600 |
51mm x 38mm |
660nm |
06 - 20 |
GS1 DataMatrix, GS1 QR Code, QR Code, GS1 DataBar, EAN/UPC, GS1-128 |
12700 |
70mm x 51mm |
660nm |
06 - 20 |
GS1 DataMatrix, GS1 QR Code, QR Code, GS1 DataBar, EAN/UPC, GS1-128 |
12800 |
24mm x 18mm |
660nm* |
03 - 20 |
Data Matrix, GS1 DataMatrix, QR Code, GS1 QR Code, Aztec, GS1 DataBar, Code 128, GS1-128, Code 39, Codabar. |
12000UV |
24mm x 18mm |
UV |
03 - 20 |
Special application for GS1 DataMatrix |
12000 OMNI |
150mm x 112mm |
660 |
03 - 20 |
GS1 DataMatrix, GS1 QR Code, QR Code, GS1 DataBar, EAN/UPC, ITF-14, GS1-128 |
* Illumination angles can be 30, 45, or 90 to meet requirements for direct-part-marked symbols. |
Hardware specifications |
Weight |
2.04 kg (4.5 lbs) |
Construction |
Cast Aluminium, CCD sensor, LED illumination |
Power consumption |
Power supply unit requires input 110 - 240vac 50/60 cycles. Power output is 12v at 0.8A. |
Interface |
USB 2.0 |
General information |
Regulatory approvals |
CE marking (compliant with RoHS and EMC directives)
Compliant with ISO/IEC 15415, 15416, 15426-1 and 15426-2
Can meet the requirements of 21 CFR part 11. |
Operating range |
Operating temperature: 10° to 40°C
Storage temperature: -20° to 70°C
Relative humidity: 25% to 80% @ 40°C non-condensing. |
Warranty |
Two years parts and labour – return to bench. |
