Axicon 12800 DPM條碼檢測儀
產品概述：
The Axicon 12800 has been specially designed to verify direct-part-marked barcodes, including Data Matrix, GS1 DataMatrix, QR Code, and GS1 QR Code two-dimensional symbols, whether laser-etched or dot peen. The smallest x-dimension is 0.127 mm or 5 mil. It has nine different lighting options to enable verification in accordance with ISO/IEC 15415 and the AIM Quality Guideline (ISO/IEC TR 29158). The Axicon 12800 allows for the angle of illumination to be set at 30o, 45o, or 90o, as required by the particular application. For 30o illumination, you can choose from four or two sides to minimise the effect of specular reflection. The field of view is 25 mm x 18 mm, and the verifier may also be used to verify linear barcodes in accordance with ISO/IEC 15416, provided they are no wider than 25 mm.
Operation
The software allows you to choose between alphabetic (ANSI) or numeric (ISO/IEC) grading of results, and analyses every module for printing defects and highlights any problem areas in the barcode. The individual data fields of a symbol can be easily recognised and checked since they are neatly parsed out of the long string of characters in some 2D symbols and identified for easy reading. The reports for each symbol can be customised, printed and saved as a PDF, and the data can be exported directly into an Excel spreadsheet.
Software specifications |
Symbologies verified |
Data Matrix, GS1 DataMatrix, QR Code, GS1 QR Code, Aztec, GS1 DataBar, Code 128, GS1-128,
Code 39, Codabar. |
Analysis performed |
ISO/IEC verification, ANSI option, or in accordance with AIM Quality Guideline (ISO/IEC TR 29158). |
Diagnostics windows |
Main screen (image of barcode, decode, grade etc), data detail, general characteristics, ISO/IEC quality parameters, AIM DPM quality parameters, scan profile, report format. |
Logging |
To PDF, HTML, CSV or text formats. Includes ability to append to PDF files |
Configurable options |
Symbology, lighting, application standard, reporting information, print format and content. |
Hardware specifications |
Dimensions |
184mm x 165mm x 177mm (7.25″ x 6.5″ x 7″) - Scan area of 25 mm x 18 mm |
Weight |
2.04 kg (4.5 lbs) |
Construction |
Aluminium, CCD sensor, LED illumination |
Power consumption |
Power supply unit requires input 110 - 240vac 50/60 cycles. Power output is 12v at 0.8A. |
Interface |
USB2 |
Wavelength of light |
660 nm |
General information |
Relative humidity |
5% to 95% at 40°C non-condensing |
System requirements |
PC running any currently supported version of Windows - USB 2.0 |
Environmental |
Operating Temperature: 0°C to 40°C |
Regulatory approvals |
CE marking, RoHS compliant. Meets ISO/IEC 15415, 15416, 15426-1 and 15426-2 standards and AIM DPM (ISO/IEC TR 29158) requirements |
Warranty |
1 year parts and labour - return to bench. |
