Webscan TruCheck 2D Omni二維條碼檢測儀 OM-1075，OM-80G，OM-150G
WEBSCAN OM-80G一維二維條碼檢測儀/條碼監測儀/條碼質量檢測
支持碼制：
Data Matrix
QR Code
GS1-DataBar (formerly RSS)
GS1-Composite Symbology
UPC/EAN
Code 128
Code 39
TLC-39
Codabar
PDF 417
Micro PDF 417 (limited to Field of View size)等等目前通用的一維、二維條碼
選型參數：
型號 |
檢測范圍 |
OM-80G |
80mm |
OM-150G |
150mm |
光源：
Narrow band 660nm LED
特征描述：
CCD Imager with Integrated Illumination
ISO grading
Data export to printer, PDF file or Excel
Software easily upgradeable
Calibrated to NIST traceable standards
Parses and validates industry standard
data formats
Variable aperture size
解碼/評級詳述：
Full ISO 15415 Grading A,B,C,D,F:Unused Error
Correction,Modulation,Axial non-uniformity,
Grid non-uniformity,Symbol Contrast,Reference
Decode,finder Pattern Damage ,Bar Width Growth
(X and Y),Quiet Zone,AIM DPM Grading :Cell
Contrast ,Cell Mod.
環境要求：
Temperature:0-40°C
Humidity:5%-95% noncondensing
一致性標準：
ISO 16022,18004,15415,15416,15426-2
Webscan TrueCheck 2D Omni OM-1075，OM-80G，OM-150G
Symbologies:
Data Matrix, QR Code, Aztex Code, GS1-DataBar (formerlyRSS), GS1-Composite Symbology, UPC/EAN, Code 128,Code 39, TLC-39, Codabar, PDF 417, Micro PDF 417, MSI Plessey, Interleaved 2 of 5, ITF-14, Laetus Pharmacode,
Optional: Postnet & IMB, UPS Maxicode
Versions
Model |
Field of View |
Min X Dim |
HD* |
100 x 75 mm |
6.0 mil |
XD |
80 x 60 mm |
6.0 mil |
Wide Angle* |
150 x 115 mm |
7.0 mil |
CRD |
88 x 66 mm |
8.33 mil |
Standard |
100 x 75 mm |
9.0 mil |
XL |
150 x 112 mm |
14.0 mil |
* Uses 5MP Camera |
Options:
GS1 Calibrated Conformance Test Card
Extended Service Plans
Light Source:
Narrow band 660nm LED
Features:
CCD Imager with Integrated Illumination
ISO grading
Data export to printer, PDF file or Excel
Software easily upgradeable
Calibrated to NIST traceable standards
Parses and validates industry standard
data formats
Variable aperture size
Decoding/Grading Analysis Specifications:
Full ISO 15415 Grading A, B, C, D, F: Unused Error Correction, Modulation, Axial non-uniformity,Grid non-uniformity, Symbol Contrast, Reference Decode,Finder Pattern Damage, Bar Width Growth (X and Y), Quiet Zone, AIM DPM Grading: Cell Contrast, Cell Mod.
Physical Characteristics:
Dimensions (LxWxD) 14 5/8” x 10 5/8” x 7 3/4”(373mm x 271mm x 196mm)
Weight: 12 lbs (5.5 kg)
Small footprint with large field of view
Environment:
Temperature: 0-40°C
Humidity: 5% - 95% noncondensing
Conformance:
ISO 15415, 15416, 15426-1&2, AS-9132, AIM DPM-2006
