Webscan TruCheck DPM激光雕刻條碼檢測儀USB-DC25D

二維條碼檢測/一維條碼檢測TruCheck Romote/USB-DC25D條碼器

激光雕刻條碼檢測儀WEBSCAN TruCheck USB-DC25D
品名：條碼檢測儀、條碼鑒定儀、條碼質量檢測儀、條碼分析儀、條碼等級檢測儀

品牌：WEBSCAN
產地：美國
型號：TruCheck USB-DC25D

優點：
1 檢測結果準確，可重復性高。
2 操作簡單，使用方便
3 報告詳細
4 連接電腦使用，非常方便地存、取、打印報告，無需配備專用的打印機

支持碼制：
Data Matrix
QR Code
Aztec Code
MaxiCode
GS1-DataBar (formerly RSS)
GS1-Composite Symbology
UPC/EAN
Code 128
Code 39
TLC-39
Codabar
PDF
417
Micro PDF 417 (limited to Field of View size)等等目前通用的一維、二維條碼
選型參數：

型號, 檢測范圍
DC25D, 25mm x 18mm

光源：
Narrow band 660nm LED自帶長壽LED光

特征描述：
CCD Imager with Integrated Illumination
USB interface to PC
ISO grading, AS 9192, AIM DPM
Data export to printer, PDF file or Excel
Software easily upgradeable
Calibrated to NIST traceable standards
Parses and validates industry standard
data formats
Variable aperture size

解碼/評級詳述：
Full ISO 15415 Grading A,B,C,D,F:Unused Error
Correction,Modulation,Axial non-uniformity,
Grid non-uniformity,Symbol Contrast,Reference
Decode,finder Pattern Damage ,Bar Width Growth
(X and Y),Quiet Zone,AIM DPM Grading :Cell
Contrast ,Cell Mod.

環境要求：
Temperature:0-40°C
Humidity:5%-95% noncondensing

一致性標準：
ISO 15415，15426-2
MIL-STD 130 （L through N）
ISO 16022,18004,16023,24778
AIQG AS9132,
AIM DPM

可選件：
GSI Calibrated Conformance Test Card
Extended Service Plans

The TruCheck 2D USB DPM barcode verifier is specially designed with 9 different lighting options to implement the AIM-DPM-2006 (ISO/IEC TR29158) method for direct part mark verification as required by US DOD MIL-STD-130N as well as many FDA UDI applications. Choose from bright field or dark field from any side to adapt to the surface texture of laser etched and/or dot peen marks. This unit is incredibly versatile and will also verify ordinary labels according to ISO 15415.

Details
With its integrated illumination, and compact size, it is easy to move the unit to where it is needed: on a label, or even on an object. The design ensures that the image is calibrated and in focus. Webscan’s broader product line incorporates these hand-held and other fixed mount versions. Choose whichever version is right for you, without compromising ease-of-use or accuracy.

Software
The TruCheck software works with all of our computer based verifiers and provides an easy to use interface to the verification hardware. Comprehensive diagnostic information that goes way beyond simply indicating the barcode grade informs users of quality problems and gives you the visibility into any quality problems that need attention.

The software analyzes every module for printing defects and highlights any problem areas in the barcode. The data content is also analyzed and checked for data formatting errors to make sure your codes met industry standards.

The individual data fields of a symbol can be easily recognized and checked since they are neatly parsed out of the long string of characters in some 2D symbols and identified for easy reading.

Reports can be customized, printed, and saved as a PDF, or you can even export your data directly into Excel with the TruCheck software. There are many additional features within the software that will assist you in perfecting your symbols. From software to hardware, Webscan designs reliable tools that will make your job easier.

Versions

Conformance
ISO 15415, 15426-2, 15426-1
MIL-STD 130 (L through N-Chg1)
ISO 16022, 18004, 16023, 24778
AIQG AS9132
AIM DPM-2006
ISO TR29158
CE Certified

Symbologies
Data Matrix
QR COde
Aztec Code
GS1-Databar
GS1-Composite Symbology
Code 128
Code 39
Codabar

Additional Features
CCD Imager with Integrated Illumination
USB 2.0 interface to PC
ISO grading, AS 9192, AIM DPM
Data export to printer, PDF file, or Excel spreadsheet
Software easily upgradeable
Calibrated to NIST traceable standards
Parses and validates industry standard data formats
Variable aperture size
CE Certified

Options
Webscan Calibration Card
GS1 Calibrated Conformance Test Card
Extended Service Plans

Physical Characteristics
Dimensions 7.25″ x 6.5″ x 7″
Weight 4.5 lbs.

Environment
Temperature 0-40 degrees
Humidity 5%- 95% non-condensing
