Opticon OPI3301藍牙無線二維條碼識讀器
該opi3301是一個持久的，但舒適的二維成像。它的重量只有110克，這是非常輕的槍型熱像儀。這種固體掃描儀可承受下降到1.5米到具體。1.3像素的成像器提供多樣化的閱讀所有標準的一維和二維條碼符號從任何方向。即插即用即插即用的opi3301能力允許用戶快速連接和操作掃描儀。
規格：
Operating indicators |
|
Visual |
1 LED (red/green/blue) |
Non-visual |
Buzzer |
Operating keys |
|
Entry options |
1 scan key |
Communication |
|
Bluetooth |
Ver. 2.0, SPP, output power class 2, range up to 10 m, 1 to 1 connection, master/slave mode, authentication and encryption |
Power |
|
Current consumption |
150mA (stand by), max 300 mA |
Rechargeable battery |
Lithium-Ion 3.7V 1100mAh |
Operating time |
Ca. 10 hours (1 scan / 5 sec) |
Charging method |
Separate cradle CRD3301 |
Battery charging time |
Ca. 3 hours (when charged with power supply), ca. 6 hours (when charged with USB) |
2D Imager Optics |
|
2D Light source |
Aiming laser diode, illumination LEDs |
2D Scan method |
CMOS area sensor, 900 x 512 pixels, gray scale |
2D Scan rate |
Up to 80 fps (excl. focusing) |
2D Trigger mode |
Manual, multiple read, auto-trigger, stand detection |
2D Image format |
Bitmap, JPEG |
2D Reading pitch angle |
-50 to 0°, 0 to +50° |
2D Reading skew angle |
-50 to 0°, 0 to +50° |
2D Reading tilt angle |
360° |
2D Min. Resolution at PCS 0.9 |
0.127 mm / 5 mil |
2D Min. PCS value |
0.45/0.3 |
2D Field of view |
Horizontal 40o, Vertical 23o |
2D Depth of field |
at Code 39 15 - 55 mm / 0.59 - 2.17 in (0.127 mm / 5 mil), 15 - 200 mm / 0.59 - 7.87 in (0.254 mm / 10 mil), 90 - 870 mm / 3.54 - 34.25 in (1.0 mm / 39 mil), at QR Code 15 - 170 mm / 0.59 - 6.69 in (0.339 mm / 13 mil) |
Supported Symbologies |
|
Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
Postal code |
Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET |
2D code |
Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code |
Durability |
|
Temperature in operation |
-20 to 50 °C / -4 to 122 °F |
Temperature in storage |
-25 to 60 °C / -13 to 140 °F |
Humidity in operation |
5 - 85% (non-condensing) |
Humidity in storage |
5 - 85% (non-condensing) |
Ambient light immunity |
Fluorescent 10,000 lx max, Direct sun 100,000 lx max, Incandescent 10,000 lx max |
Drop test |
1.5 m / 5 ft drop onto concrete surface |
Vibration test |
10 - 100 Hz with 2G for 1 hour |
Protection rate |
IP 42 |
Physical |
|
Dimensions (w x h x d) |
56 x 137 x 113 mm / 2.20 x 5.39 x 4.45 in |
Weight body |
Ca. 110 g / 3.9 oz (incl. battery) |
Case |
ABS, Black or White |
Regulatory & Safety |
|
Product compliance |
CE, FCC, VCCI, RoHS, IEC 60825-1 Class 2, IEC 62471, IEC 60825-1 Class 1, IEC 60950-1 |
應用：
保健應用：藥房管理；電子病歷登記；校內護理；效率記錄跟蹤；
零售應用：項目鑒定；價格檢查；手機優惠券；忠誠卡識別
倉庫管理應用：發貨確認；內部分配；庫存檢查；交貨跟蹤；荷載驗證
移動票務應用：入口控制；檢查跟蹤訪問者的數據存儲
附件：
配件：
單獨出售crd3301是的crd3301充電和通信的opr3301搖籃（激光）的…
